Doppler effect correction support high speed moving.
高速行進中仍可清楚收視數位節目
Support USB and SD card reader function
支援USB及SD卡播放
Feature:
Use DiBcom dib9080M high performance NIM chip with diversity structure
使用知名法國 DiBcom 解碼 IC
Speed over sd 230km/h min (at 8k, 64QAM,CR2/3.GI1/8,474MHz)
經測試SD超過 180km/h min 仍可清楚收看數位節目
High Doppler effect correction
Provide antenna power supply function for pair use with mobile active antenna
可支援天線供電
Stores Over 1000 TV & radio programs
Channel list editing
喜愛頻道設定
Favorite channel list editing
Support USB Interface
PIG (Picture in Graphic) support
video YC output
On screen channel information
USB supports mp3/mp4(avi/mpg/dat/vob)/jpeg
使用USB播放MP3/MP4(AVI/MPG/DAT/VOB檔)/JPEG.
OSD Teletext (DVB ETS 300 706) and subtitle function support (EU model)
VBI Teletext support (EU model)
Fast scan for high speed driving and cross difference area
Wide DC power input
Technical Specification
Tuner RF input: VHF-H 174MHz~230MHz, UHF 470~862MHz
Nominal input impedance: 75ohm
Signal level: -81dBm~-25dBm
Connector: F type terminal x 2
Channel bandwidth: 6M/7M/8M selectable
COFDM carrier mode: 2K and 8K Non Hierarchical/Hierarchical
Constellation: QPSK, 16QAM, 64QAM
Guard inrterval: 1/32, 1/16, 1/8, 1/4
Code rate(FEC): 1/2, 2/3, 3/4, 5/6, 7/8
MPEG Transport Sream A/V decoding
Transport stram: ISO/IEC 13818-1 MPEG-2
Video aspect ratio: 4:3 / 16:9
Video system: PAL / NTSC
Audio decoder: MPEG-1/2 Layer I and II
Audio Channel: R/L/stereo
IN/OUT port
CVBS video outpurt
Y/C (S-video) output
IR remote command input
RS-232 input
I2C I/O port
USB & SD card function
General
SUNPLUS 1002 RISC CPU
8Mbit Flash Memory
64Mbit SDRAM
Operation temperature: -10~50
Storage temperature: -20~80
Power Supply: DC 7V~12V
Power consumption: Running 3.0W max, Standby: 2.4W max
Physical Specification
Dimension: 40(L)x80(W)x11(H)mm
Weight: 48g
